Product Model | Cover | Hole distance of hinge cup | Hinge cup diameter | Hinge cup depth | Opening angle | Applicable door thickness | Maximum load | Material | Surface treatment |
DZ-361-01 | Big Bend | 48mm | 35mm | 11.5Mom | 95 degrees | 16-25mm | 5kg/2 Only | Cold rolled steel | Nickel-plated |
DZ-361-03 | Middle Bend | 48mm | 35mm | 11.5Mom | 95 degrees | 16-25mm | 5kg/2 Only | Cold rolled steel | Nickel-plated |
DZ-361-06 | Straight Bend | 48mm | 35mm | 11.5Mom | 95 degrees | 16-25mm | 5kg/2 Only | Cold rolled steel | Nickel-plated |
DZ-362-01 | Big Bend | 48mm | 35mm | 11.5Mom | 95 degrees | 16-25mm | 5kg/2 Only | Cold rolled steel | Nickel-plated |
DZ-362-03 | Middle Bend | 48mm | 35mm | 11.5Mom | 95 degrees | 16-25mm | 5kg/2 Only | Cold rolled steel | Nickel-plated |
DZ-362-06 | Straight Bend | 48mm | 35mm | 11.5Mom | 95 degrees | 16-25mm | 5kg/2 Only | Cold rolled steel | Nickel-plated |
